Product Introduction
The GDL5 Locating Flat Liquid Leak Detection Tape is specially designed for detecting the leakage and drips of conductive liquids. When used in conjunction with the Locating Leak Detection Controller, it has the Locating detection function. The resistance of each meter of the detection tape is 13 ohms. If the Locating Leak Detection Tape detects the liquid, it will trigger the Locating Leak Detection Controller and send out an alarm signal. This leak detection tape is lightweight, flexible, foldable, and easy to install. It uses double-sided adhesive tape and can meet various needs.
Product Parameters
Once the GDL5 Locating Flat Liquid Leak Detection Tape detects a leak, it immediately outputs a trigger signal for the controller. It can be directly laid on the ground, installed inside equipment, or wrapped around pipes. It has flexible installation methods.
Product Certification
The Locating Flat Liquid Leak Detection Tape has obtained various certifications such as CE, ROHS, FCC, and those issued by the metrology institute.
Typical Application Industries of the Product
The Locating Flat Liquid Leak Detection Tape is suitable for data centers, semiconductors, new energy, photovoltaic power, petroleum and petrochemicals, and power environment systems. It can not only detect water but also various weakly acidic and alkaline liquids.
Compatibility with Detection Cables
The Locating Flat Liquid Leak Detection Tape can be used in conjunction with the GLD4100 Leak
Detection Controller.
Technical Specifications
| Cable Material | PET + Alloy Wire |
| Core Resistance | 13 Ω per meter |
| Cable Color | White |
| Cable Size | 12mm wide, 0.2mm thick, sensing interval 25mm |
| Tensile Strength | 20KG |
| Cable Weight | 10g per meter |
| Maximum Exposure Temperature | 85℃ |
